設備信息：

MACHINE SPECIFICATIONS 設備參數

The Whizard? Motor is highly effective for use in the meat industry, designed with the highest

possible standards for safety, ergonomic design, production and yield efficiency.

The Whizard? Motor Assembly Unit described in this Operation Instruction has been tested by

an independent and certified body, Inchcape Testing Services (UK) Ltd, ETL Albury, Cranleigh,

Surrey, England and complies with the Low Voltage Directive 73/23/EEC and EMC 89/336/EEC

which includes conformity with the following standards:

產品符合低壓電器指導條例 73/23EEC 和 EMC 89/336/EEC，并達到如下標準：

In addition, this product also conforms with the following Swiss standards IEC 745 and HD

400.1 and also conforms with American standards USDA, ANSI 3.34 and ETL approved to

UL763 (115V units only).

瑞士標準 IEC745 和 HD 400.1，并符合*** USDA，ANSI 3.34 和 ETL 標準。

General Whizard? Motor Information:

Power Requirements:

EN 50081-1 IEC 801

EN 50082-1 IEC 335-1

EN 60335-1 IEC 335-1

Weight 24 lbs. (10.9 kg) 重量：10.9 公斤

Overall Size 22” High x 11” Wide x 7-1/2” Deep

(530mm) x (280mm) x (190mm) 長 X 寬 X 縱向長度

230VAC 1 Phase 50Hz 230 伏 單向 50 赫茲

440W 2.7 A 2850 RPM 440 瓦 2.7 安培 2850 轉/分鐘
